Telecommunication
& Fiber optics
Melos Cable Compounds are an ideal solution for the use in the field of data transmission systems.
Telecommunications & Fiber optics
Melos Cable Compounds are an ideal solution for the use in the field of data transmission systems.
Cable Compounds for Telecommunication & Fiber Optics
Products table
MELOS CODE
Operating temperature [°C]
Shore hardness
Tensile strength [N/mm²]
Elongation at break [%]
LOI [%]
Density [g/cm³]
Viscosity [g/10 min] MFI Mooney [MU]
Oil resistance level
Special features
Standards
Applications
MECOLINE S
TP 1005 F
TP 1005 F
-15 to 90
57 D
10.0
180
37
1.52
150°C/ 21.6 kg
3.5
+ HM2, HM4, HM5, TM7+ BS 7655 LTS1/ LTS2/LTS3/LTS4+ SHF1+ CEl 20-11 M1, NF C 32-323
MECOLINE S
TP 1006 F
TP 1006 F
-25 to 90
50 D
10.3
179
45
1.56
160°C / 21.6 kg
5.0
+ HM2, HM4, HM5, TM7+ BS 7655 LTS1/ LTS2/LTS3/LTS4+ SHF1+ CEl 20-11 M1, NF C 32-323
MECOLINE S
TP 1007 F
TP 1007 F
-25 to 90
54 D
11.2
180
34
1.52
150°C / 21.6 kg
11.1
+ HM2, HM4, HM5, TM7+ BS 7655 LTS1/ LTS2/LTS3/LTS4+ SHF1+ CEl 20-11 M1, NF C 32-323
MECOLINE S
TP 1021 F
TP 1021 F
-30 to 80
48 D
10.8
226
42
1.48
150°C / 21.6 kg
9.0
+ HM2, HM4, HM5, TM7+ BS 7655 LTS1/ LTS2/LTS3/LTS4+ SHF1+ CEl 20-11 M1, NF C 32-323
MECOLINE IS
TP 1033 F
TP 1033 F
-25 to 90
53 D
13.0
185
39
1.51
190°C / 21.6 kg
12.8
+ HM2, HM4, HM5, TM7+ BS 7655 LTS1/ LTS2/LTS3/LTS4+ SHF1+ CEl 20-11 M1, NF C 32-323
MECOLINE S
TP 1039 F
TP 1039 F
-70 to 105
34 D
11.8
219
44
1.63
210°C / 21.6 kg
3.6
+ HM2, HM4, HM5, TM7+ BS 7655 LTS1/ LTS2/LTS3/LTS4+ SHF1+ CEl 20-11 M1, NF C 32-323
